IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface

IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface

  • CAT.NO: QM1571
In-Store Only
$103.00$129.00
Save $26.00

Store

Choose a store for stock availability
IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface
$103.00
Batteries IncludedUSB 2.0Wireless

A quality true RMS multimeter with a wireless USB computer interface, non-contact voltage indicator, relative zero and data hold. Double moulded housing is impact resistant and quite durable, and IP67 waterproof rating makes this DMM capable of even the harshest conditions. Wireless USB interface and included logging software allow for computer based live data logging whilst keeping your computer completely isolated and protected.

Features:

• IP67 waterproof
• True RMS
• Wireless USB interface
• PC logging software
• Auto power-off
• Backlight
• Non-contact voltage
• Data hold
• Diode test
• Autoranging
• Audible continuity
• 10A current range
• Double moulded case
• Display 4000 count
• Security Class Cat IV 600V
• Basic DCV accuracy 0.500%
• Temperature -20°C to +760°C (±3.0%)
• Ave/RMS True RMS
• Special features Wireless USB, IP67, True RMS, non-contact voltage

Digital Multi-Meter

True RMS

true

Autorange

true

Meter

Meter Input Impedence

10.0 MΩ

Measures diode

true

Input Protection Fuse

10.0mA,500.0mA

Casing

Plastic

Carry Case Included

true

Power from disposable battery

Size / Shape

9V

Battery quantity

1.0 pc

Batteries included

true

Batteries can be replaced by user

true

Compartment location

Internal / In-built

How is battery compartment kept closed

Clip and Screw

Meter Data Control

Data Hold

true

Relative Measure

true

Meter PC Interface

DMM Control from PC

true

Live Refresh

false

Meter Safety Rating

Safety Category

Cat IV

Safety Rating Max Volt

600.0 V

Meter Probes

Probe rating voltage

4000.0 V

Probe safety rating

Cat IV

Measures Voltage AC

AC Voltage Ranges

400.0mV,4.0V,40.0V,400.0V,1000.0V

AC Voltage Accuracy

0.8 %

Measures Voltage DC

DC Voltage Ranges

400.0mV,4.0V,40.0V,400.0V,1000.0V

DC Voltage Accuracy

0.5 %

Measures Current AC

AC Current Ranges

4.0mA,40.0mA,400.0mA,10.0A

AC Current Accuracy

1.8 %

Measures Current DC

DC Current Ranges

4.0mA,40.0mA,400.0mA,10.0A

DC Current Accuracy

1.2 %

Measures Resistance

Resistance Ranges

400.0Ω,4.0kΩ,40.0kΩ,400.0kΩ,40.0MΩ

Resistance Accuracy

0.8 %

Measures Capacitance

Capacitance Ranges

4.0nF,40.0nF,4.0µF,40.0µF,100.0µF

Capacitance Accuracy

3.0 %

Measures Frequency

Frequency Ranges

4.0kHz,40.0kHz,400.0Hz,4.0MHz,10.0Hz

Frequency Accuracy

1.5 %

Measures Continuity

Continuity indicator

Needle

Measures Temperature

Measures in Celcius

true

Measures in Fahrenheit

true

Outdoor / Exterior Scale

-20.0°C-760.0°C

Celcius Accuracy

3.0 %

Ingress Protection Rating

Dust/Particle Ingress Protection

6 - Dust tight, no ingress of dust

Liquid/Moisture Ingress Protection

7 - Immersion up to 1m

IP Rating certificate

true

Product Dimensions

Length

170.0 mm

Width

79.0 mm

Height

50.0 mm

Packaged Dimensions

Packaged Dimensions

21.5cm(Length) x 15.5cm(Width) x 6.0cm(Height)
