12.8V 100Ah Lithium Deep Cycle Battery

12.8V 100Ah Lithium Deep Cycle Battery

  • CAT.NO: SB2215
On special
$649.00$919.00
Save $270.00

Available variants (12)

Store

Choose a store for stock availability
12.8V 100Ah Lithium Deep Cycle Battery
$649.00
Hazardous Materials3 Year WarrantyDelivered for $25

The next generation of power storage is here! These LiFePO4 batteries may look fairly similar to lead acid batteries, but internally they’re a totally different, next generation concept. They’re actually made up of regular pouch LiFePO4 cells, which are in mass production for many portable devices. An internal battery management system (BMS) ensures all cells are uniformly charged and discharged, as well as providing short circuit, over current, and reverse polarity protection. This provides you with a higher degree of protection than a traditional lead acid battery which is unprotected, and can discharge rapidly under short circuit conditions, causing fire and damage. The internal BMS will also limit discharge and manage cut-off voltage, to further protect the internal cells.

This 100Ah model can provide continuous current up to 100A, with peaks of up to 150A. It’s not suitable for a primary vehicle starting battery, however is absolutely perfect for house batteries, backup batteries, and virtually any other application where you would typically use a large lead acid / AGM battery.

Features:
- Much lighter than Lead Acid and AGM Batteries
- Robust LiFePO4 Cells
- 10+ years life span
- 100amp continuous output



Specifications:
Service Life: 10yrs+
Cycle Life: 1500+ cycles (> 80% capacity retention)

Able to run 4 batteries in parallel or 2 in series.

Operating Temperature and Humidity

Operating Temperature

45.0°C-45.0°C

Operating Humidity

85.0%,85.0%

Storage Temperature and Humidity

Storage Temperature

0.0°C,40.0°C

Storage Humidity

0.0%,50.0%

Battery Charging

Recharging Voltage

14.6V,14.6V

Standard Recharge Current

40.0 A

Charging Method

Constant Current,Constant Voltage

Batteries

Battery usage

Bulk Storage

Battery Chemical Composition

Lithium Ferrous Phosphate (LiFePO4)

Battery Peak Current

150.0 A

Amp Hour Rating

100.0 Ah

20 Hour Capacity

100.0 Ah

Internal Resistance

60.0 mΩ

Connection Type

M8 Bolt/Nut

Type of battery

li-ion

Peak Discharge Duration

5.0 sec

Continuous Current

100.0 A

Nominal Voltage

12.8 V

Cut-Off Voltage

9.2 V

DC Voltage Rating

DC Voltage

12.8 V

Product Dimensions

Width

325.0 mm

Height

220.0 mm

Depth

170.0 mm

Weight

11.0 kg

Classified as dangerous goods

DG UN Number

3480.0

DG Class

9.0

DG Pack Group

II - Medium Danger

DG Hazardous Chemical Code

4W

DG Ship Name

3480 - Lithium Ion Batteries

Battery Watt Hour Rating (Required for Lithium Batteries)

1.0 Wh

Packaged Dimensions

Packaged Dimensions

38.0cm(Length) x 20.0cm(Width) x 25.0cm(Height)
