Powertech Battery Box with Power Accessories

Powertech Battery Box with Power Accessories

  • CAT.NO: HB8504
$77.95

Store

Choose a store for stock availability
Powertech Battery Box with Power Accessories
$77.95

This portable 12V battery box has all the common connections you would typically need for your outdoor recreation power needs. The box with carry handles is capable of holding a deep cycle battery up to 100Ah (sold separately), which secures in place with the supplied webbing strap. High current power connectors include two 50A Anderson Style Connectors, insulated bolt terminals (wing nut), and a 12V cigarette lighter socket with over current protection. There is also a dual-port USB to charge your Smartphone and similar USB devices, and a voltmeter to help monitor the battery level.

Features:
• Suits batteries up to 100Ah
• Dual 50A High Current Plugs
• 12V Cigarette Socket
• Dual USB Ports
• LED Voltmeter
• Circuit Breaker Switch

Specifications:
Dual-Port USB: 5VDC 1A, 5VDC 2.1A
Power Socket: 12VDC, 16A
High Current Connector: 50A

Measures Voltage DC

DC Volts Measurement Range

30.0V,30.0V

DC Voltage Rating

DC Voltage

12.0 V

DC Current Rating

DC current rating

20.0 A

Product Dimensions

Width

424.0 mm

Height

306.0 mm

Depth

251.0 mm

Weight

2.0 kg

Dimension details

External Dimensions

Additional Dimensions

Width

330.0 mm

Height

217.0 mm

Depth

185.0 mm

Dimensions details

To Suit Maximum Battery Size

Internal or Sub-part Dimensions

Width

338.0 mm

Height

220.0 mm

Depth

206.0 mm

Dimension details

Internal Dimensions

Packaged Dimensions

Packaged Dimensions

43.7cm(Length) x 28.6cm(Width) x 34.7cm(Height)
