Digitech 3-Way Optical TOSLINK Splitter

Digitech 3-Way Optical TOSLINK Splitter

  • CAT.NO: AC1590
Digitech 3-Way Optical TOSLINK Splitter
Digitech 3-Way Optical TOSLINK Splitter
Digitech 3-Way Optical TOSLINK Splitter
Digitech 3-Way Optical TOSLINK Splitter
$29.95

Bulk Pricing

Qty 1 - 3

$29.95 / Unit

Qty 4 - 9

$26.95 / Unit

Qty 10 +

$23.95 / Unit

Store

Choose a store for stock availability
Digitech 3-Way Optical TOSLINK Splitter
$29.95
1 Year WarrantyUSB 2.0
Allows a combined optical cable length of 40m with no audio quality loss. Audio format support for LPCM2.0, DTS and Dolby AC-3 with signal re-timing for perfectly synchronized audio. USB powered and features voltage overload protection. Includes USB charging cable.

Specifications:
  • Inputs: 1 x TOSLINK (Optical)
  • Outputs: 3 x TOSLINK (Optical)
  • Frequency: 96KHz
  • Baud Rate: 16Mbps
  • Audio: LPCM 2.0, DTS, Dolby AC-3
  • Supported Cable Length: 40m (Total)
  • Power: 5VDC, 500mA (USB Mini B)
  • Power Consumption: 200mA (Maximum)
  • Dimensions: 60(W) x 54(D) x 20(H)mm
Product Dimensions

Width

62.0 mm

Height

21.0 mm

Depth

58.0 mm

Packaged Dimensions

Packaged Dimensions

13.5cm(Length) x 2.5cm(Width) x 10.5cm(Height)

Manual for AC1590
