110W Folding Solar Panel and Charge Controller

CAT.NO: ZM9175

$309.00

Bulk Pricing

Available variants (2)

Store

Choose a store for stock availability

110W Folding Solar Panel and Charge Controller

$309.00

Overview

Almost a staple for camping trips, folding solar panels are the go to for keeping your deep cycle batteries charged while away. This Powertech 12V Folding Solar Panel provides an extra 10W of power compared to older designs with the same physical size, which means you can charge your batteries more efficiently without having to lug around larger panels. This product includes two 55 Watt monocrystalline solar panels that provide excellent performance under low light environments, producing 2-3% more power and higher kWh/kW ratio compared to older monocrystalline designs. The 10A PWM solar charge controller features power status LEDs and a handy 5V 1.2A USB port to charge your phone and other USB gadgets at the campsite. Suitable for charging AGM/Lead acid, Gel and Flooded batteries, and supplied with a 5m lead with Anderson connectors, extension leads (Anderson to eye terminals and Anderson to Alligator Clips), and a heavy duty bag for safe portability. Equipped with a carrying handle, durable fold out legs that allow for varying degrees of tilt, and industry standard latches, this solution will be your new best friend for on the go!

25 year limited warranty

All Powertech monocrystalline solar panels are covered by a 25 year limited warranty. This warranty covers the panels for defects in construction and manufacturing for a period of 5 years, and warrants that the electrical output will remain above 80% of its original rated output for a period of 25 years.

Features:

- Adjustable, corrosion-resistant aluminium stand and frame

- Heavy duty handle and latches for longevity

- PWM Solar charge controller compatible with gel, sealed, and flooded batteries

- 5V 1.2A USB Port

Specifications

Solar Panel

Solar panel type

Monocrystalline

Cover Material

tempered glass

Open Circuit Voltage

21.5 V

Short Circuit Current

6.56 A

Voltage at Power Max

17.9 V

Current at Power Max

6.15 A

Power Connector

Anderson Connector

DC Voltage Rating

DC Voltage

12.0 V

Power Rating

Maximum Power

110.0 W

Product Dimensions

Length

1.0 mm

Width

665.0 mm

Depth

35.0 mm

Cable length

5.0 m

Dimension details

Unfolded

Internal or Sub-part Dimensions

Length

525.0 mm

Width

665.0 mm

Depth

75.0 mm

Dimension details

Folded

Packaged Dimensions

75.0cm(Length) x 15.0cm(Width) x 60.0cm(Height)

Downloads

Manual for ZM9175
